D-UN-DY-23 Dell Unity Deploy 2023 Exam Questions and Answers

To grant access of a Dell Unity XT provisioned NFS datastore to an ESXi host, the permission level required for the host depends on the NFS protocol and authentication method used by the NAS server. For NFSv4 with Kerberos NFS owner authentication, the ESXi host must have the Read/write, enable Root permission level. This allows the ESXi host to read and write data to the datastore, as well as perform administrative tasks such as creating and deleting virtual machines. The Read/write permission level alone is not sufficient, as it does not allow the ESXi host to perform root-level operations on the datastore. The Read-only permission level only allows the ESXi host to read data from the datastore, but not write or modify it. References: Dell EMC Unity: Configuring hosts to access NFS1, page 9.

The service task that the administrator should perform to fix the issue with minimal impact is Restart Management Software. This service task restarts the management software on both storage processors without affecting the data services or the host I/O. This can resolve the communication issues between Unisphere and the storage system. Reinitialize, Enable SSH, and Reboot Storage Processor are service tasks that have more impact and risk than Restart Management Software.

A LUN is a logical unit of storage that is presented to a host as a SCSI device. A LUN is composed of one or more RAID extents, which are the smallest units of storage that can be allocated to a LUN. A RAID extent is a slice of a RAID group that is used to store user data and parity information. The size of a RAID extent depends on the RAID type and the drive type of the RAID group. For example, a RAID 5 extent on a SAS drive is 128 MB, while a RAID 6 extent on a NL-SAS drive is 256 MB. The LUN is partitioned into slices that match the size of the RAID extents, and each slice is mapped to a RAID extent from a RAID group in the storage pool. The LUN slices are distributed across multiple RAID groups to improve performance and availability. References:

Dell EMC Unity: Storage Pools and RAID Groups

Dell EMC Unity: LUN Management

To apply the management IP from the vSphere UnityVSA console, the system administrator must use the svc_initial_config command. This command allows the user to configure the initial network settings for the UnityVSA, such as the management IP address, subnet mask, gateway, and DNS servers. The svc_ipmi command is used to configure the IPMI settings for the UnityVSA, such as the IPMI IP address, username, and password. The svc_change_hw_config command is used to change the hardware configuration of the UnityVSA, such as the number of CPU cores, memory size, and disk size. The svc_inject command is used to inject faults into the UnityVSA for testing purposes.

When Advanced Deduplication is disabled on a LUN, the existing data that was deduplicated remains in its reduced state, and only new data written to the LUN is not deduplicated. To remove the Advanced Deduplication savings from the LUN, the administrator must perform a Local LUN Move operation, which copies the data from the source LUN to a destination LUN without deduplication. The destination LUN must have Advanced Deduplication disabled, and must be in the same storage pool as the source LUN. After the Local LUN Move is completed, the source LUN can be deleted and the destination LUN can be renamed as the original LUN. References: Dell Unity: Data Reduction2, page 9.

The Unity XT 680 system supports four types of I/O modules: 12 Gb/s SAS back-end, 4-Port 16 Gb Fibre Channel, 4-Port 25 Gbps Ethernet, and 4-Port 10 Gbps Ethernet. The 12 Gb/s SAS back-end module provides connectivity to the disk drives and expansion enclosures, while the other three types of modules provide network connectivity to the hosts and clients. The Unity XT 680 system has six I/O module slots, three for each SP. The 12 Gb/s SAS back-end module must be installed in slot 0 of each SP, and the other modules can be installed in slots 1 and 2 of each SP. Therefore, the correct answer is D. 12 Gb/s SAS back-end. References:

Dell EMC Unity XT: Hardware Information Guide

Dell EMC Unity XT: Installation Guide

A characteristic of Host Groups is that block storage resources added to a host group are accessible to all the member hosts. A Host Group is a logical grouping of hosts that share the same access permissions and settings for block storage resources. By adding block storage resources to a host group, the user can simplify the management and allocation of storage for multiple hosts. Access to block storage resources does not need to be set before adding hosts to a host group, as the access permissions can be modified later. Hosts added to a host group can have mapped block storage resources, as long as they are not in conflict with the host group resources. Block storage resources attached to one of the member hosts are not accessible to the entire host group, unless they are also added to the host group.

To expand a dynamic pool, the number of drives added must be equal to or greater than the stripe width of the pool. The stripe width is the number of data drives plus the number of parity drives in a RAID group. In this case, the stripe width is 12 + 1 = 13. Therefore, the minimum number of drives needed for the pool expansion is 13. References: Dell EMC Unity: Dynamic Pools Technical White Paper1, page 8.

The snapshot option that is set automatically when a pool is configured is the Pool Automatic Deletion Policy. This option determines how the system handles the deletion of snapshots when the pool reaches a certain threshold of capacity utilization. The user can choose between three policies: Never Delete, Delete Oldest, or Delete Lowest Priority. The Total Pool Consumption and the Snapshot Pool Consumption are not snapshot options, but rather metrics that show the amount of pool space consumed by the pool data and the snapshots respectively.
