The workstation's IP configuration (192.168.1.27/24 with gateway 192.168.1.1) shows that it has a correct IP address, correct subnet mask, and expected default gateway for a typical small office network. Because the IP is in the correct private range and not an APIPA address (169.254.x.x), this also confirms that DHCP is functioning properly. Therefore, option D (DHCP) cannot be the cause.

The user then pings the default gateway at 192.168.1.1, which should be the router—the device providing routing between local devices and outside networks. The repeated "Request timed out" responses indicate the workstation cannot reach the router at all. This type of failure points directly to a router outage, a powered-off router, a failed router interface, or a physical disconnection of the router from the switch.

If DNS (C) were the issue, the user would still be able to ping the IP address of the gateway because DNS is not required for IP-to-IP connectivity. A web server (A) has no relation to local gateway communication and does not affect workstation access.

Since the workstation has a valid IP but cannot reach its default gateway, the failure point is the router.

A Layer 3 switch is the optimal solution when multiple VLANs must intercommunicate while maintaining high performance and minimal hardware complexity. CompTIA A+ explains that Layer 3 switches combine the capabilities of switching (Layer 2) and routing (Layer 3), allowing VLAN traffic to be routed internally at wire speed, without the latency typically associated with traditional routers.

Layer 3 switches use hardware-based routing, meaning they forward inter-VLAN traffic using ASICs (Application-Specific Integrated Circuits). This allows them to achieve extremely fast throughput, ideal for environments like computer training institutes where multiple VLANs may be used for student labs, instructor networks, and administrative traffic.

A router (D) can route between VLANs but introduces more latency due to software-based routing and typically requires additional equipment. A Web application firewall (A) and DDoS appliance (B) are security devices unrelated to internal VLAN communication.

Because the institute requires minimal hardware and high-speed inter-VLAN communication, the Layer 3 switch is the only CompTIA-supported device that meets both requirements simultaneously.

RAID 0 (striping) provides the fastest read (and write) speeds at the lowest cost, as all disk capacity is used for storage and performance. However, it offers no redundancy.

From CompTIA A+ 220-1101 Official Study Guide, Objective 3.4 – RAID types:

"RAID 0 stripes data across multiple disks, offering the best performance and lowest cost but no fault tolerance."

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 3: RAID Levels

CompTIA Exam Objectives 220-1101, Domain 3.4
