Cisco 300-420 Dumps Questions Answers

The selected configuration sets are correct because the addressing plan must use VLSM to maximize subnets and minimize wasted addresses. Customer A requires 125 hosts, so it needs a /25 subnet, which provides 126 usable host addresses. Customer D requires 62 hosts, so it needs a /26 subnet, which provides 62 usable addresses exactly. Point-to-point or small WAN links B, C, and E should use the smallest appropriate link subnets shown in the exhibit, typically /30 for IPv4 point-to-point links when two usable addresses are required. A correct plan must allocate the largest blocks first, align every subnet on the proper boundary, avoid overlap, and avoid assigning a larger-than-needed subnet to any customer or link. Options A and C are the two valid combinations that satisfy those rules in the exhibit. Any option that places a /25 or /26 on the wrong boundary, overlaps with another block, or wastes larger subnets on links would fail the design objective. Reference topics: IPv4 VLSM, subnet boundary alignment, host capacity planning, point-to-point addressing, route summarization readiness.

The primary capability of IaaS in this question is elastic scaling: the ability to increase or decrease infrastructure resources based on demand. In Infrastructure as a Service, the provider offers compute, storage, and network resources as an on-demand service, while the customer deploys operating systems and applications on top of that infrastructure. Cisco cloud material describes this model as providing scalable IT capacity without requiring the organization to own all physical assets. Option C is the best answer because dynamic capacity adjustment is a fundamental cloud capability and a major reason enterprises choose IaaS for variable workloads. Option B is a valid business benefit because consumption-based billing can reduce cost, but the question asks for a primary capability, not the pricing model. Option D describes automation and orchestration, which support cloud operations but are not the specific capability being tested. Option A is closer to hybrid-cloud workload mobility and is not guaranteed by IaaS alone. Reference topics: cloud service models, IaaS, elasticity, scalable compute, on-demand resource provisioning.

AS-path prepending is the correct inbound path-control tool for this design. The objective is for traffic entering AS100 to use link 1 during normal operation and link 2 only after a failure. In BGP, the AS_PATH attribute is a primary path-selection attribute used by external autonomous systems; a shorter AS path is normally preferred over a longer path. By prepending AS100 multiple times on advertisements sent from R4 across link 2, AS100 makes the backup path look less attractive to upstream networks while leaving it available for failover. Modifying next-hop on R3 or R4 does not influence how external networks choose between two entry points into AS100. Prepending on R3 would make the preferred link less attractive, which is the opposite of the requirement. The design should also document provider policy because some providers local-preference routes before AS path, but within the choices, prepending on R4 is the appropriate inbound traffic-engineering method. Reference topics: BGP AS_PATH, inbound path control, multihoming, backup Internet edge design.
